Tio, the toy kit designed to inspire tomorrow’s inventors

Tio Inventors

Invent Play Learn Ltd is the company behind Tio, the kit to build app-controlled toys and inventions in seconds. The Tio kit encourages creativity and long term play by combining the feeling of creating with your own hands and the power of today’s technology. It comprises connected hardware, magnetic mounts, wheels and other accessories that can be attached to almost anything including recycled and craft material, lego, old toys, gadgets and even 3D prints. Using the kit, adults and children alike, can create an infinite number of toys and animate the world around them.

The interactive learning app customises and programs the toys. It controls many features like speed, direction and colours. Key to the experience is the Tio storybook, full of friendly characters who guide children through imaginary worlds and their first creations. The Tio team shares a vision to inspire tomorrow’s inventors with a new way of inventing, playing and learning.

Tio product development

Rob Bakewell, our project manager responsible for delivery of the Tio prototypes, tells the story from our workshop:

“In the early phase of the project, we were approached by co-founder, Peter Spence, to produce some 3D printed components to test his digital design for the Tio parts. To make these, we used our Objet Printer with VeroClear resin. This material has properties similar to acrylic and is transparent, so Peter was able to clearly see the internal details of the parts. This step in the prototyping process aided Peter to develop the design further.

Once the design development phase was complete, Peter approached us again with the brief to produce casing units for fully working prototypes of the Tio units. The challenge was to create eight units for demonstration purposes – and these needed to be attractive enough to enter competitions and underpin the Kickstarter campaign for Tio.

At the time, Invent Play Learn was in start-up phase – a situation where we can tailor our processes to produce the best results within the budget. Their requirements’ brief was very specific:
– To achieve high tolerance parts, allowing for moving components and magnets.
– To accommodate electronics and lighting, adding to the visual appeal.
– To apply a soft ‘tyre’ over the wheel detailing.
– To have a crisp finish and be bright in colour.
– To be robust enough to survive the impact of trial playing and regular usage.

Developing your invention prototype

The first step for the prototype was to produce new 3D prints, which were then prepared as vacuum casting masters. Peter had adjusted the design since the first round of components were printed, and specified the desired finish. This means the parts required hand-finishing to achieve a high gloss finish for all clear components, and a smooth satin finish for the coloured components. Parts are always checked for fit, and then we invite the product designer or inventor in to double-check them and discuss development. Once these components were ready for Tio, we went ahead with the tooling.

Trimming an elastomer vacuum casting

Making the prototyping process more efficient

To ensure we produced these components as efficiently as possible, we created multi-cavity moulds to then vacuum cast multiple parts of similar size and material in selected single moulds. Our process always protects the critical dimensions and fine detailing. Once the silicon moulds were complete, then the fun began with the casting process.

Each component was cast in the appropriate material, which is where knowledge of plastics and experience in the casting team is critical. To fit with Peter’s brief, we selected optic clear and high impact ABS for the Tio components. ABS are resins from the family of thermoplastics, called terpolymers, because they are made of three different monomers: Acrylonitrile, Butadiene and Styrene. ABS is created as a single material that draws on the best properties of all three. We had Pantone references for a few of the favoured bright colours for the Tio prototypes, which we then colour matched during the casting process.

Assembling your prototypes

For this project, our service included fitting the magnets and constructing the eight fully working cases, ready for the electronics to be fitted. So the next phase was most interesting – assembling the units and seeing the parts come together. In some projects, the inventor or designers take the component parts back to their team for further development. For Tio, Peter spent a day with us, assisting with some of the final assembly, and fitting printed circuit boards and motors. The large volume of components stayed with us, to be fettled and adjusted for fit to meet the critical dimensions of the design. Working this closely with the client allowed us to make sure we produced exactly what he required to bring the Tio kit to life.

Meeting your product development timescale

As with many of our projects, timing was critical for Peter to have a functioning prototype ready to launch Tio. These parts needed to be turned around in a very short amount of time, so Invent Play Learn could film their digital content and promote it around the world. We were delighted to see the team win NACUE’s Varsity Pitch and will continue to watch their progress!

Following the successful delivery of the Tio prototypes, Peter says “we are happy with the quality of Amalgam’s work and their speed of delivery. We have been running many workshops with children, parents and teachers and are delighted to say the prototypes have delivered on every front, in particular enabling us to bring the product and our mission to life. Since the delivery of the prototypes, we have been able to create appealing visual assets to use with traditional and social media as well as to move forward with our plans to launch a Kickstarter campaign at the beginning of 2016.”

Based in Central London, Tio was dreamt up by three aspiring innovators with a vision to inspire tomorrow’s inventors. Kids at heart, they are dedicated to creating a new way of inventing, playing and learning. Tio was recently featured in the Daily Telegraph, Guardian, Huffington Post and E&T Magazine.

To follow Tio’s progress and for more information about the product, visit tiotoys.com, sign up at tiotoys.com/sign-up, like Tio on facebook.com/createtio and follow them on Twitter
